HGPS3002 microscopic imaging probe station
HGPS3002 microscopic imaging probe station
Product features:
1. Equipped with 5x23.5mm, 20x10.4mm, 40x7.0mm working distance objective lens;
2. Three-eye imaging module, CCD interface;
32,000 megapixel USB3.0 microcamera.
4.XYZ axis adopts stepping motor screw motion control;
5. Movement accuracy 1μm;
6. Set 30mm light source hole under the objective lens of the platform;
7. X-axis: moving stroke is 400mm; Y-axis: moving stroke is 100mm; Z axis: mobile stroke is 100mm.
序号 | 名称 | 数量 | 参数 |
1 | XYZ移动平台 | 1 | 1.XYZ轴采用步进电机丝杆运动控制； 2.移动精度1μm； 3.平台对应物镜下方设置30mm光源孔； 4.X轴：移动行程为400mm； 5.y轴：移动行程为100mm； 6.Z轴：移动行程为100mm。 |
2 | 生物显微镜成像系统 | 1 | 1.配备5X23.5mm，20X10.4mm，40X7.0mm工作距离物镜； 2.三目成像组件，CCD接口； 3.2000万像素usb3.0接口显微摄像头。 |
3 | 移动光源 | 2 | 1.led光源； 2.照射光斑直径10mm； 3.光源亮度可调节； 4.光源头部可移动位置，此光源主要用于照射目标上表面用。 |
4 | 底光源 | 1 | 1.led光源，安装于移动平台光源孔内； 2.照射光斑直径10mm； 3.光源亮度可调节； 4.此光源主要用于穿透透明物体成像。 |
5 | 培养皿上盖吸盘 | 2 | 1.采用卡槽吸盘，可通过水平移动取下吸盘； 2.采用支架固定于移动平台上方。 吸盘用于吸住培养皿上盖 |
6 | 探针臂及探针 | 1 | 探针规格为： 直探针：1微米针尖2根，5微米针尖2根，10微米针尖2根，50微米针尖2根，100微米针尖2根； Z型探针：1微米针尖2根，5微米针尖2根，10微米针尖2根，50微米针尖2根，100微米针尖2根；（可根据需求随意匹配）。 |
7 | 底板 | 1 | 采用光学底板，底部M6螺纹孔，孔距25mm，用于固定移动平台、移动光源、探针臂，固定位置可更换。 |
8 | 软件控制系统 | 1 | 软件应包含视野区，移动控制功能键，光源调节功能键 |
产品实拍
4 to 6 inch vacuum suction chuck
4 to 6 inch vacuum suction chuck
Product features
1. High quality 304 stainless steel;
2. Fine iron after grinding, flatness to 5 μm;
3. The standard size is 4 inches and 6 inches, the surface is equipped with 3 and 4 adsorption holes respectively, special size can be customized, according to customer demand supporting vacuum adsorption pump.
产品实拍
HGPS005 Probe adjusting seat
HGPS005 Probe adjusting seat
Product features：
★ three axis translation adopts high-quality micrometer head with high driving accuracy;
★ the guide rail adopts precision cross roller guide rail to ensure straightness;
★ high quality tension spring reset to eliminate mechanism clearance;
★ integrated modular design, compact structure and elegant appearance;
★ installation method: the base plate contains magnetism, which can be absorbed by magnetism, or can be installed on the optical platform with M6x10 socket head cap screw.
HGPS100 Probe table
HGPS100 Probe table
Product features:
1. The probe table is mainly used in the research and development of precision electrical measurement of semiconductor industry, photoelectric industry, integrated circuit and packaging, complex and high-speed devices, in order to ensure quality and reliability, and reduce the research and development time and the cost of device manufacturing process.
2. HGPS100 probe station is a manual probe station with complete configuration, good integrity and economic benefits. It is applicable to IGBT, FRD, voltage and current test, solar cell test, diode transistor test and back electrode test in dry wafer factories, research institutes and universities.
3. In addition to conventional component related tests, HGPS100 probe table is also widely used in crack detection, flaw detection and jewelry identification of various materials and devices.
HGPS02 Probe adjusting seat
HGPS02 Probe adjusting seat
Product features
★ HGPS02 probe adjustment seat adopts modular and exquisite design, supporting HGPS01BT probe arm, and three probe installation modes of horizontal / vertical / 45 °, with high cost performance and wide application range;
★ the probe base is specially designed to insulate the conductive part from the base plate to prevent electric leakage and ensure the measurement accuracy;
★ the probe clamping is convenient and fast, and the probe clamping rod is all copper design with good conductivity;
★ base installation method: the base is magnetic adsorption type and can also be fixed with screws.
HGPS01B Three dimensional probe adjusting seat
HGPS01B Three dimensional probe adjusting seat
Product features
★ Yunke HGPS01B probe adjustment seat adopts modular design, including three-dimensional fine adjustment table, probe clamp, table adapter, probe clamping rod, base, etc;
★ the fine adjustment table adopts British fine tooth screw fine adjustment control, with a pitch of 0.635mm;
★ the probe clamping rod clamp is made of non-metallic insulating material, Insulate the conductive part from the displacement table to prevent leakage accidents;
★ the probe clamping is convenient and fast to ensure convenient use. The probe clamping rod is all copper design with good conductivity;
★ HGPS01BT horizontal probe arm is used in combination with various installation methods: horizontal, vertical and 45 degrees. Humanized design truly realizes multiple uses of a product, which is economical and suitable for a variety of testing occasions.
